WFQ-B Computer High-speed Slitting Machine

0086-577-58910222
DESCRIPTION

 Performance and Characteristics:
This machine is used for slitting and rewinding various large rolling materials such as paper,(
20g-300g/)cellophane paper,bill paper,double-face adhesive tape,PVC,weave material,nowoven of cloth,etc.Adopt A and B pneumatic shaft structure for rewinding.It adopts photoelectric automatic error correction adjustment system for unwind-ing,anomalistic materials will be easy slit.(or liquid press style subtense system)Equipped with automatic waste film blowing device.(vertical knife structure)Manual material loading for unwinding(or pneumatic automatic material loading)with taper cover style pneumatic shaft.(3’,6’)

Main Technical Parameter:

Model

WZFQ- 1100C

WZFQ- 1300C

WZFQ- 1600C

Max.width of unwinding

1100mm

1300mm

1600mm

Max.diameter of unwinding

Φ1400mm

Φ1400mm

Φ1400mm

Min.width of slitting

20mm

20mm

20mm

Max.diameter of rewinding

Φ500mm

Φ500mm

Φ500mm

Max.Speed

200m/min

200m/min

200m/min

Precision of slitting

±0.2mm

±0.2mm

±0.2mm

Total Power

7kw

7kw

8.5kw

Suitable power supply

380V/50Hz

380V/50Hz

380V/50Hz

Weight(approx)

2100kg

2300kg

2600kg

Overall dimension(LxWxH)

2850x2150x1350(mm)

2850x2350x1350(mm)

2850x2650x1350(mm)




Inquiry

If you have any enquiry about quotation or cooperation,please feel free to email us at ray@sanbi.comor use the following enquiry form. Our sales representative will contact you soon. Thank you for your interest in our products.
